| Model |
V7204 |
V7208 |
| Compression |
H.264 (Main Profile) |
| Signal Format |
HD-SDI (1080p, 1080i or720p, Manual-detection) |
| Video Input |
4 HD-SDI Inputs (1080p, 1080i or720p) |
| VGA / HDMI Output |
1 VGA / 1 HDMI (Max. 1920 x 1080p, Various Resolution) |
| Recording Rate |
120FPS at 720p or 60FPS at 1080p |
240FPS at 720p or 120FPS at 1080p |
| Dual Stream |
Selectable |
| Audio Compression |
ADPCM (16 Bit) |
| Audio Input |
4 Inputs (RCA Jack) |
8 Inputs (RCA Jack) |
| Audio Output |
1 Output (RCA Jack) |
| Ethernet |
10 / 100 / 1000 Mbps Ethernet (RJ-45) |
| PTZ Control |
RS-485/422 Serial Port 1 (Terminal Block) |
| POS |
4 |
| Alarm Input |
4 (TTL) Programmable as NC/NO |
8 (TTL) Programmable as NC/NO |
| Alarm Output |
4 (TTL) Programmable as NC/NO |
8 (TTL) Programmable as NC/NO |
| USB Port |
4 x USB (2 x Front Panel, 2 x Rear Panel) |
| Recording Qualities |
Super / High / Standard |
| Recording Modes |
Continuous / Alarm / Motion / Emergency |
| Pre-Alarm Recording |
up to 3 Hours / User Programmable |
| Motion Detection |
Yes (22 X 15) |
| Playback Speed |
X1, X2, X4, X8, X16, X32, X64, Extreme |
| Archive File Format |
EXE (Video Clip) / JPEG (Still Image) |
| NTP Server |
Yes |
| GMT Time Zone |
Yes |
| Auto DST |
Yes |
| Multi Language |
English / Danish / Chinese (Traditional) / Japanese / Korean / Italian / Polish / Russian / Chinese (Simplified) / Thai / Turkish / Spanish / French / Czech / German / Persian / Portuguese / Croatian / Arbic |
| 3G Communication |
MS Mobile (Professional 6.1 or Higher) / Android / Blackberry / iPhone |
| Operating System |
Embedded Linux |
| OS Firmware |
Linux OS in Flash Memory |
| Emergency Recording Key |
Yes |
| Primary Storage |
SATA Hard Disk Drive (up to 4+1) |
| Clip Copy Storage |
Built-in Internal DVD-RW, Memory Stick |
| Dimension(WxHxD) |
430 mm x 88 mm x 380 mm / 16.93 inch x 3.46 inch x 14.96 inch |
| Operating Temperature |
5`C~40`C / 41`F~104`F |
| Operating Humidity |
0% ~ 90% |
| Power Adapter |
Free Voltage 12VDC, 6.67A |
| Power Consumption |
Max 80W |
| Agency Approval |
FCC / CE / UL (NRTL) |
